Who doesn’t like sitting exterior with a superb fall breeze and a few crisp air? It’s lastly time to begin preparing for fall, what higher method than constructing a superb hearth pit. Seize a set of plans and comply with together with this video so I can present you ways I made mine.
Let’s Construct a Hearth Pit
DIY Hearth Desk Plans
$9.99
I’ve created a set of plans to make constructing this hearth pit tremendous easy and straightforward to comply with.
Supplies I Used for this Construct
- Wooden
- Wooden Glue
- Noticed
- Nails
- Brad Nailer
- Wooden End
- Casters
- Hearth Pit Plans
Step 1: Constructing the Hearth Pit Body and Assembling
The very first thing I’m going to do is construct a body from 2x4s. This shall be a giant field to cover the propane tank wanted to feed the hearth. I deliberately purchased a tank that may safely be laid down on it’s aspect so I might preserve my desk decrease to the bottom. By the best way, in order for you a minimize listing and dimensions of this desk, I’ve a set of plans for it over on my web site. If this desk is just too huge for you, I even have a smaller model out there
After utilizing the miter noticed to chop down just a few 2x4s, I assembled them. I first lay out all my components to do a dry match. This fashion I can make sure that all of it appears to be like proper earlier than sticking issues collectively. Right here I’m utilizing exterior rated wooden glue and some screws on every joint. That is designed in order that the highest boards overlap the joints of the underside boards. This can create power but it surely additionally makes it fast to place collectively.
Step 2: Creating the Bins Physique
Subsequent shall be to sheath it, to place plywood across the body to create the field’s physique. Since this shall be exterior, I’m utilizing an exterior plywood that’s handled. I additionally painted the skin faces which you’ll see I’m ensuring to attaching pointing in direction of the skin of the physique.
It’s because I plan to do a slatted design exterior of this layer and wished a darkish coloration to be in between every slat. I’m attaching these sheets by first pre drilling then working in a screw alongside the underside. Then additionally working in a screw to attach the highest of the boards collectively. When going into skinny wooden like this 1/2” plywood, I swap over to utilizing trim head screws like these right here.
Step 3: Framing out the Prime and Attaching it to the Physique
The following factor I did was body out the highest aspect. These members will give me assist to safe the highest within the subsequent step. They are often tough so as to add since there’s nothing besides the plywood to attach them to the underside framing so what I did was use a clamp to carry it in place as soon as I received it lined as much as the highest of the ply. Once more utilizing the trim head screws to safe it. I began with the 2 longer items then related the 2 shorter sides in between.
Alrighty, now lets throw the highest on. That is one other piece of exterior rated plywood that I painted the highest aspect of. The opening within the middle shall be the place the hearth tray will get inserted later. I lined it as much as the physique then secured it down by first pre drilling across the perimeter then working in some screws. Throughout I made positive to sink the heads of the screws in order that nothing would stop the slats that may come subsequent, to attaching flush to the physique.
I’m going to go away that as is for a bit and begin making the slats that may cowl it.
Step 4: Making the Slats to Cowl the Physique
For this half I’m going with western crimson cedar 1×4 boards. That is what’s going to take this boring field and switch it into one thing beautiful to take a look at. I began by taking my full size boards and ripping them to width on the desk noticed. I made the slats half the width so two slats might come out of 1 board. Now I’m going to go together with a water fall look in order that the highest boards will miter over into the aspect boards. To realize this, I turned my desk noticed blade to a forty five and used the miter gauge to
minimize the boards to size. When organising my fence, I place a clamp and a scrap board to behave as a cease block. Discover how I place this far sufficient again on the fence in order that the board will now not be touching this scrap as soon as it contacts the blade. If it contacts each on the identical time, it creates a pitch zone which causes kickback. This can be a quick technique to make tons and plenty of repetitive cuts.
To place the miters collectively, I exploit exterior wooden glue as soon as once more then additionally reenforce the joint with just a few 23 gauge brad nails. Good and easy. Subsequent I repeated that very same course of to create a complete bunch of them. For the reason that sample is similar in all 4 quadrants, I might prep all of the components and have them staged on my workbench. This additionally gave the glue time to arrange.
Step 5: Making use of the Slats to the Hearth Pit Physique
With that achieved, this subsequent step will fly. Lets begin making use of the slats to the physique. So the perimeters may have verticals that come up and meet the highest slats. With that, I would like the highest protecting the tip grain of the verticals so I make sure that to carry up a scrap to get the spacing right. You possibly can see I transfer it alongside as I work on securing that first board, however then after that the remainder can get laid down with only a spacer. I additionally transfer this spacer alongside to ensure the slat is getting connected parallel the whole size of the board. See me utilizing it on the highest but in addition on the aspect.
My spacer is only a random scrap I discovered to be the dimensions wanted for the hole. After I get to the within most slat, I maintain it in place in order that I can go to the within with a pencil and mark the middle gap opening. I believe it’s simpler to chop this now with a bandsaw however know you could additionally connect it and minimize it after the actual fact with a jigsaw or perhaps a flush trim bit in a router. The fireplace tray with cowl it so no must make it tremendous fairly.
Step 6: Creating the Propane Tank Door
I’m utilizing just a few streaks of DAP Dyna grip on every one among these earlier than the brad nails. That is my favourite building adhesive because it’s extremely quick setting and works for each inside and exterior initiatives. You possibly can see subsequent I repeated a lot of the identical course of however this time with simply straight vertical boards. These are butted up proper to the underside of the overhanging high slat and I make sure that to make use of the identical spacer so issues stay constant.
All these slats hold previous the physique barely as a result of I personally wished casters on mine in order that I could make this factor cellular when not in use. The overhanging quantity will cowl the added top. This huge hole right here shall be a detachable panel to permit me to entry the within propane tank. I’m utilizing magnets right here and fix them by counterboring into the framing materials then screwing in a magnet.
Now I can connect a washer on a screw to the door on all 4 corners to correspond to those magnets. As soon as the door is in place, I might repeat the method of attaching verticals to make it disappear into the physique.
Step 7: Making use of End to the Hearth Pit
Lets go forward and put a coat of end on them to actually see them pop. With a view to get in all of the nooks and crannies of the perimeters of the slats, I’m spraying on my end however you can completely simply roll or brush it on as a substitute. I’m utilizing my Wagner HVLP which makes very fast work of this step. For a end I’m going with the Complete Boat Gleam 2.0 because it dries rapidly, does a terrific job at leveling out on it’s personal, and what I most like is that it has UV resistors in it so this cedar will maintain up despite the fact that it is going to be exterior.
Step 8: Including Casters to Make the Hearth Pit Cell
Oops, If forgot to point out you after I connected the casters. However again after attaching all of the slats, I tiled the field over and screwed on just a few casters which is what’s permitting me to rotate this factor round to point out you all sides.
I personally like the thought of it having casters on it as a result of it’ll solely be getting used throughout the winter months however for the summer season months, I like the thought of pushing it out of the best way and utilizing this house for one thing else. As soon as I picked out the place I wished my hearth desk to be I began loading within the home equipment to make it work. The tray slips proper into the middle opening and comes with fairly easy directions on hooking it as much as a propane tank.
You possibly can’t lay a standard propane tank on it’s aspect so should you construct one among these you both want to revamp it so it will possibly stand upright or purchase one that’s designed particularly to be laid over.
Step 9: Ending particulars! Including Rocks, Chairs, and Drinks!
Now I must fill it with rock, seize my transportable chair, and a drink and luxuriate in. As you’ll be able to see there’s loads of house for firm to hitch me and likewise loads of house to set drinks or a plate of meals on the unit itself. Nevertheless keep in mind that I’ve plans for this bigger unit but in addition a extra compact unit should you’re all in favour of constructing one your self.
Conclusion
If a hearth pit has been in your to do listing then I hope this video has given you some good inspiration to sort out it this fall. You should definitely try my web site for a set of plans for this construct in addition to a number of others. I’ll see you on no matter I’m constructing subsequent.
